The 1764-24AWA is a high-performance MicroLogix 1500 Base Unit manufactured by Rockwell Automation. It serves as the foundation for a programmable controller, integrating power, I/O, and communication in a compact, scalable footprint.
Core Specifications
- I/O Configuration: Features 12 discrete AC inputs (120V AC) and 12 relay outputs (24–125V DC / 120–240V AC).
- Power Supply: Operates on a wide line power range of 85–265V AC.
- Communication: Includes an integrated RS-232 port for peer-to-peer networking and external device connectivity.
- Expandability: Supports up to 512 I/O points via expansion modules, making it ideal for small to medium automation projects.
Key Technical Features
- Capacity: High load capacity with up to 8A per common for relay outputs.
- Compatibility: Designed for use with 1764-LSP and 1764-LRP processors.
- Reliability: Industrial-grade design with a fast 20ms response time and horizontal mounting.
- Efficiency: Consumes 70 VA of power with a maximum load of 16W.
